Text Box: Name:  C61





Saturday, March 19, 2005

C62_013_pt_overview_2_close

Text Box: Image Filenames and Comments Vol. 6 p 22.  Difficult to get ion beam to focus.  Small fleck of gold remain in sample hole 100nm x50.   Reference holes are excellent, and small.  Calculate contrast and compare with results. Take Care since the gold is pealing off.


Membrane Parameters

Size (μm)

200x200

Thickness (nm)

100

Frame size( mm)

5x5

Frame thickness (μm)

200

Dwell: 1.0 μs

Overlap: 50%
