Text Box: Name:  C59

Text Box: Image Filenames and Comments See vol. 6 page 19-20 also see C59_table.doc   Only the larger reference hole penetrated, but it does look pretty good, smaller than expected.  1)Interesting because there is a partially drilled reference hole that is very small. 2) Calculate the expected contrast and compare with the experiment.  Both reference hole and sample hole are small, but multilayer is thin.


Membrane Parameters

Size (μm)

~75x124

Thickness (nm)

100

Frame size( mm)

5x5

Frame thickness (μm)

200



Dwell: 1.0 μs

Overlap: 50%
